DIY 30 Ton Shop Hydraulic Press Brake – Digital Build Plans

This listing is for the digital build plans for my “Garage Shop 30 Tons DIY Hydraulic Press Brake”.

This press brake was design to be the perfect size to fit a home garage or small shop.

What makes this pressbrake stand out amongst the rest is that it has features to make repeatable bends. This makes it possible with limit switches to control the vertical distance and a numerically control backstop.

Watch the build video on my YouTube channel here: https://youtu.be/z9YKuXz_h7I

The approximate cost for the build with all the bells and whistle is ~$3,000

-Steel Frame ~ $250
-Cyclops Design Press Brake Tool ~ $1400
-Hydraulics Cylinder ~$160
-Electric Hydraulic Pump ~$270
-Hardware Components~ $450

Press Brake Features:

1. Cyclops Press Brake Tool – Comes with Segmented Dies and 4-way V-Block, 610mm Bending Width, Order this through Tom @ enquiries@cyclopsdesigns.co.uk
2. Limit Switches to make repeatable bends
3. NC Backstop
4. Control Box
5. Auto-Retract
6. Electric Pump so no need for compress air

This tool is roughly 6ft tall 3ft front to back and 3ft wide

With your purchase of this listing this is what is included:

1. Easy to follow Step-by-Step Guide 23 pages. (cutlist, assembly instructions, wiring diagram, 2D template, etc)
2. DXF Files (cut files) for all custom sheet parts
3. Excel Spreadsheet of cutlist, links on where to buy, and total lengths of steel tube
4. Tonnage/Thickness Reference Sheet
5. Control Box Wire Diagram

Tag me on social if you’re building this project (@ratha.sochenda on Instagram) also check my stories to follow the build.

These plans are for private/personal use only. You may not produce or sell this commercially without permission. Do not copy or redistribute these files.
